The wireless charging system mainly includes : “full bridge inverter”, “transmitting and receiving control” and “MOS driving circuit”
● Full bridge inverter: low voltage DMOS transistor
● Transmitting and receiving controller: wireless power transfer MCU; Wireless Power Transmitting Control Circuit; Wireless Power Receiving Control Circuit
● MOS driving circuit: high speed MOS driving transistor
| Product Model | Product Encapsulation | Product Category |
|---|---|---|
| CS4268LO | MSOP10 | 高速MOS驅動電路 |
| CS4268LO | MSOP8 | 高速MOS驅動電路 |
| CS4268LO | MSOP10 | 高速MOS驅動電路 |
| CS4978EN | QFN24 | 無線充電接收端控制電路 |
| CS4977EF | QFN40 | 無線充電接收端控制電路 |
| CS4967EF | QFN48 | 無線充電發送端控制電路 |
| CS4968EN | QFN48 | 無線充電發送端控制電路 |
| CS49P60EF | QFN32 | 無線電能傳輸MCU |
| CS4268LO | MSOP10 | 高速MOS驅動電路 |
| CS4977EF | QFN40 | 無線充電接收端控制電路 |
